Monospan Steel Profile |
Corrugated Steel Profile |
Insulspan Corro/Corro |
Insulspan Technical Specifications
Wind Classification as per AS4055:2012 Valid for both Monoclad/Trimdeck and Corrugated 0.42 BMT Top Sheet with 0.5mm BMT underskin
Fire Hazard
| Early Fire Hazard AS 1530.3 | ||
| Index | Test Range | |
| Ignitability | 0-20 | 12 |
| Spread of Flame | 0-10 | 0 |
| Heat Evolved | 0-10 | 3 |
| Smoke Developed | 0-10 | 5 |
Spans for building and conditions not complying with the above parametres should be referred to a Structural Engineer.
Panel Weight
| 50 mm | 75 mm | 100 mm | 125 mm | 150 mm | |
| Kg/ m2 | 8.8 kg/m2 | 9.1 kg/m2 | 9.3 kg /m2 | 9.5 kg /m2 | 9.7 kg /m2 |
Insulation Factors
| 50 mm | 75 mm | 100 mm | 125 mm | 150 mm | |
| R Value m/ Kw | 1.39 | 2.09 | 2.78 | 3.48 | 4.18 |
Standard Products
| EXTERNAL | CORE | INTERNAL |
| Monospan Corrospan( corrugated iron) Selected Colours (Please contact your nearest PTI branch for further details) |
'SL' Grade expanded Polystyrene with flame retardant additive |
0.5mm Off white steel |
Colours
